Technical Specifications
Parameter |
Value |
|---|---|
| Display | 7″ Colorful TFT Capacitive Touch Screen |
| Resolution | 1024×600 |
| Operating System | Android 10.1 |
| RAM | 2 GB |
| ROM | 8 GB |
| CPU | Embedded high-performance processor |
| Audio Input/Output | Built-in microphone & loudspeaker; adjustable volume |
| Alarm Inputs | 8 |
| Alarm Outputs | 1 relay output |
| Network Connectivity | WiFi (2.4GHz, IEEE802.11b/g/n), RJ-45 Ethernet (10/100 Mbps) |
| Communication Protocols | TCP/IP, SIP, RTSP |
| RS-485 Interface | 1 (half-duplex) |
| TF Card Support | Up to 128GB |
| Power Supply | 12V DC (1A) or IEEE802.3af PoE |
| Power Consumption | ≤12W |
| Installation | Surface mounting |
| Working Temperature | -10°C to +50°C (14°F to 122°F) |
| Working Humidity | 10% to 90% (non-condensing) |
| Dimensions (W×H×D) | 187mm × 137mm × 25.7mm (7.36″ × 5.39″ × 1.01″) |
| Weight | Net: 419g; Gross: 694g |
| Languages | Multilingual: English, Russian, Spanish, French, etc. |
| Application | Indoor use |
Additional Features
- Receives brief video verification (7 seconds) from alarm systems
- Table stand (DS-KABH6320-T) available for desktop use (optional accessory)
- Surface mounting for walls
Typical Usage
Perfect for apartments, villas, commercial buildings, offices, and smart home automation environments. Offers user-friendly property access, intercom, and monitoring solutions — all in one smart device.
Frequently Asked Questions
1. What is the HIKVISION DS-KH9310-WTE1(B)’s display size and resolution?
For crisp and vibrant images, the device has a 7-inch colorful TFT capacitive touch screen with a resolution of 1024 x 600.
2. Are Android apps compatible with the DS-KH9310-WTE1(B)?
Indeed, it is compatible with a number of smart home integrations because it runs on Android 10.1 and allows the installation of Android apps.
3. Can I watch the device’s live camera feeds?
Indeed, the intercom station integrates with the Hik-Connect app for real-time monitoring and supports live view from up to 16 network cameras.
4. Can this device be used in a commercial setting?
Of course. Because of its sophisticated features and compatibility with alarm systems, it is perfect for both residential and commercial settings, including villas, apartments, offices, and retail stores.
